Specifications
| Body diameter | φ13mm |
| Body length | 25.4 / 31.4 / 37.4mm |
| Peak torque | 7 / 15 / 25 mN·m |
| Max speed | 3,000 rpm |
| Max encoder resolution | 11 bit |
| Model | MDS-1306 | MDS-1312 | MDS-1318 |
| L1 length | 25.4 | 31.4 | 37.4 |
- * For MDH (hollow-flange shaft type) motors with an absolute encoder, the through-hole is not open.
Dimensions & Wiring
MDS-13
Speed–Torque Curves
MDS-1306
MDS-1312
MDS-1318
| Unit | MDS-1306 | MDS-1312 | MDS-1318 | |
| Supply voltage (driver input) | DCV | 24 | ||
| Max speed (*1) | rpm | 3,000 | ||
| Rated speed | rpm | 3,000 | ||
| Peak torque | Nm | 0.007 | 0.015 | 0.025 |
| Continuous stall torque | Nm | 0.003 | 0.005 | 0.008 |
| Continuous rated torque | Nm | 0.003 | 0.005 | 0.008 |
| Peak output | W | 2 | 4 | 8 |
| Peak power rate | kW/s | 4.5 | 13 | 27 |
| Peak current | Arms | 2.6 | 2.6 | 2.6 |
| Continuous rated current (*2) | Arms | 1.1 | 1 | 1 |
| Back-EMF constant (equiv.) | V/krpm | 0.28 | 0.61 | 1 |
| Torque constant (equiv., at 25°C) | Nm/Arms | 0.0027 | 0.0058 | 0.0096 |
| Phase-to-phase armature resistance (25°C) | Ω | 1.1 | 1.8 | 2.5 |
| Phase-to-phase armature inductance | mH | 0.13 | 0.21 | 0.39 |
| Rotor poles | P | 8 | ||
| Encoder max resolution (*3) | P/R | Absolute: 2,048 (11 bit) | ||
| Rotor inertia J | g·cm^2 | 0.11 | 0.17 | 0.23 |
| Allowable radial load Fr | N | 20 | ||
| Allowable axial load Fa | N | 10 | ||
| Allowable moment | Nm | 0.39 | 0.5 | 0.61 |
| Repeatability (reciprocating) | Pulses | ±1 | ||
| Mass | kg | 0.04 | 0.05 | 0.06 |
| Recommended drivers | MC-200C-7220 / MC-200C-6018 | |||
| Reference heatsink | 55 × 55 × 4 (Aluminum) | |||
- * If you need a different maximum speed, please contact us.
- * Continuous rated current measured at 40°C ambient with the reference heatsink attached to the motor.
- * If you need a different encoder resolution, please contact us.
Drivers
| Manufacturer | Driver (amplifier) model | Interface | Power | Notes |
| MTL | MC-200-7220A | Pulse train, USB | DC 24/48 V | General-purpose compact |
| MC-200-7220D | SPI, USB | DC 24/48 V | General-purpose compact | |
| MC-200C-6018D | SPI, USB | DC 24/48 V | Ultra-compact |
- * For MC-200-7220A, please prepare the CN4 connector/cable on your side. (Connector model: 10136-3000 PE)
- * For MC-200C, CN1/CN4 connector cables and CN2/CN3 converter cables are included.
Options in Use
MC-200-7220A
MC-200-7220D
MC-200C-6018D
