Rotary Encoder Options Pricing Reference
Flexible options for easier customization
At MTL, one of our core policies is to help customers create the equipment they need through flexible customization. Among these requests, options with high versatility or relatively low technical difficulty can often be supported as standard options.
Please use the table below to find the option that best matches your requirements.
- If your request is not included in the option lineup, we may still be able to support it through customization or new development.
- If you need a vacuum specification, shaft extension, or a specified connector, please contact our sales team first.
- You can also contact us at mtl@mtl.co.jp.
Note: The table below applies to the ME-30P series. Some options may not be available for other models.
| Option | Part Number Notation | Overview | Reference Price |
|---|---|---|---|
| Cable Length Change | Add cable length at the end, for example (3M), (5M), (10M) | Changes the cable length. Available lengths are 3 m, 5 m, and 10 m. | +¥990, +¥1,650, +¥3,300 (Varies depending on output circuit and other specifications.) |
| Hollow Bore Diameter Change | Add the bore diameter at the end | Changes the hollow bore diameter. Supported sizes are φ8 and φ12. | +¥2,000 |
| Set Screw Mount Shaft | Add F1 + bore diameter at the end, for example F1(φ8) | Changes the hollow shaft to a set screw fixing type. The encoder hollow shaft and the machine shaft can be fixed directly with set screws for easier installation. Supported bore sizes are φ8, φ10, and φ12. | +¥2,000 |
| Connector for DC Counter | Add K or KZ at the end. For wire encoders, add it after the resolution. | Adds a connector for connection to our DC counter. If Z-phase output is also required, the model code changes. Connector model: ER05-PB5F. | +¥2,000 (Varies depending on output circuit.) |
| Output Signal Reversal | Add CCW at the end | Includes a conversion cable to reverse the output signal when used together with a DC counter. | +¥5,000 |
| Z-Phase Mark | Add MZ at the end | Adds a mark so the Z-phase output timing can be identified from the outside. | +¥5,000 |
| Coupling GJ6x6 | Specify “with coupling GJ6x6” or equivalent notation | Includes a coupling compatible with the MES-30. | +¥440 |
| Without MEH30 Flange | Specify “without flange” or equivalent notation | The flange is omitted. It is normally included because it is required for mounting. | -¥550 |
| Issuance of Calibration Certificate | Specify “with calibration certificate” | Issues a calibration certificate, inspection report, and traceability certificate. | +¥33,000 |
Need a different specification?
If you cannot find the option you need in the list above, please contact us. We may still be able to support your request through customization.
